In stock
| Series | AFO |
|---|---|
| Code | AF400GR |
| Type | AFO.2/2+2/GR |
| Colour | Grey |
| HS code | 85369010 |
| TECHNICAL FEATURES | |
| Function/Type | Feed-through with fast-on connections |
| Rated cross-section | 2.5 mm² |
| Connecting capacity | |
| Flexible wire | < 2.5 mm² |
| Rigid wire | ‒ |
| Wire with ferrule - ferrule type | – |
| Electrical characteristics according to IEC EN standard | |
| Maximum voltage AC/DC | 630 V |
| Maximum current (rated cross-section) | 20 A |
| Caliber | – |
| Electrical characteristics according to UL Standard | |
| Maximum voltage AC/DC | 600 V |
| Maximum current (rated cross-section) | 15 A |
| Section (min-max) | – |
| Tightening torque value (UL) | – |
| Electrical characteristics according to ATEX directive and IEC Ex standard | |
| Maximum voltage AC/DC | – |
| Maximum current (rated cross-section) | – |
| Operating temperature Min/Max | – |
| Rated impulse withstand voltage / pollution degree | 6 kV / 3 |
| Insulation stripping length | – |
| Tightening torque value (nom. / max.) | – |
| Widht (pitch) | 6.5 mm |
| Length | 44 mm |
| Height mounted on TH35-7.5/TH35-15/G32 | 49 / 57 / 52 mm |
| Insulation material temperature index (EN 60216-1) | 130 °C |
| Plastic material | Polyamide UL94V-0 |
| ACCESSORIES | |
| End section | |
| Grey | AFO/PT/GR (cod. AF201GR) |
| Blue | – |
| Beige | AFO/PT (cod. AF201) |
| Thickness | 1.5 mm |
| Cross-connection | |
| Model A) | – |
| Rated current carrying capacity IEC/ATEX | – |
| Cross-connection identification strip | – |
| Multiple cross-connection bar | – |
| Shunting screw and sleeve (Standard / Exe) | – |
| Protection cover | – |
| Coloured partition plate | DFU/1/R (cod. DU01R) |
| Cross-connection barrier | – |
| Test plug socket | – |
| Marking | |
| Single marking tag | CNU/8/51 (cod. NU0851S) – CNU/10/61 (cod. NU1061S) |
| Single marking tag for pitch insertion | – |
| End bracket | |
| TH35 screw type | BT/3 (cod. BT003) |
| TH35 snap-fit type | BTO (cod. BT007) |
| TH35 and G32 snap-fit type | BTU (cod. BT005) |
| Mounting rail | |
| IEC 60715/TH35 | PR/3/… |
| IEC 60715/G32 | – |
| APPROVALS AND MARKINGS |     |
For further information see PDF catalog
