Original price was: €136,20.€74,91Current price is: €74,91. + VAT
In stock
In stock
| Series | CR |
|---|---|
| Code | XCR81 |
| Type | CR8-1 |
| HS code | 85364190 |
| INPUT TECHNICAL DATA | |
| Input rated voltage | 24 Vac/dc ±10% |
| Pull in / drop out voltage type | 16.8 V / 2.4 V |
| Current consumption | 16 mA ±10% |
| Turn ON / OFF time | 7 ms / 3 ms |
| Protection circuit | Free-wheel diode, Reverse polarity |
| Connection terminal | 2.5 mm² screw type pluggable |
| Input channels | 8 not pluggable |
| OUTPUT TECHNICAL DATA | |
| Contact type | SPST(NO), 1 Form A (NO), AgSnO2 |
| Nominal current | 8 A (240 Vac) |
| Continuous current | 8 A |
| Connection type | |
| GENERAL TECHNICAL DATA | |
| Operating temperature range | -20…+70°C |
| Input / output isolation | 2.5 kVac / 60 s |
| Protection degree | IP 20 |
| Overvoltage category / pollution degree | II / 2 |
| Status indication | LED "DC OK" / LED "Relay" |
| Housing material | UL94V-0 plastic material |
| Dimensions (LxHxD) | 119x108x22.5 mm |
| Approximate weight | 199 g |
| Mounting information | on a rail, side by side |
| ACCESSORIES | |
| Mounting rail (IEC60715/TH35-7.5) | PR/3/AC, PR/3/AC/ZB, PR/3/AS, PR/3/AS/ZB |
| Spare part relay | 8904042 |
| APPROVALS AND MARKINGS |   |
For more information, download the PDF catalog
