| Series | |
|---|---|
| Code | X766083 |
| Type | CWOT 6-2083 (1) |
| INPUT TECHNICAL DATA | |
| Input rated voltage | 24 Vdc (range 10…40 Vdc) |
| Pull in / drop out voltage type | 5 V / 5 V |
| Current consumption | 6 mA ±10% at 24 Vdc |
| Turn ON / OFF time | 12 μs / 12 μs |
| Frequency | 1 KHz |
| Protection circuit | Free-wheel diode |
| Connection terminal | 2.5 mm² screw |
| Input channels | 1 not pluggable |
| OUTPUT TECHNICAL DATA | |
| Contact type | transistor (2) |
| Output voltage | 5…48 Vdc |
| Nominal current | 10…500 mA (24 Vdc) |
| Connection type | |
| Protection circuit device | suppressor diode |
| GENERAL TECHNICAL DATA | |
| Operating temperature range | -25…+60°C |
| Input / output isolation | 3.5 kVac / 60 s |
| Protection degree | IP 20 |
| Overvoltage category / pollution degree | II / 2 |
| Status indication | LED "Input" |
| Housing material | UL94V-0 plastic material |
| Dimensions (LxHxD) | 84x79x6.2 mm |
| Approximate weight | 29 g |
| Mounting information | on a rail, side by side |
| ACCESSORIES | |
| Mounting rail (IEC60715/TH35-7.5) | PR/3/AC, PR/3/AC/ZB, PR/3/AS, PR/3/AS/ZB |
| APPROVALS AND MARKINGS |   |
For further information see PDF catalog
