€70.00 + VAT
In stock
In stock
3-phase filter with neutral IN: 440 Vac 10 A
| Series | TY |
|---|---|
| Code | XF10TYG9 |
| Type | F10TYG9 (1) |
| HS code | 85363010 |
| GENERAL TECHNICAL DATA | |
| Rated voltage | 440 Vac ± 10% |
| Continuous current | 10 A |
| Leakage current | 0.5 mA |
| Frequency | 50…60 Hz |
| Operating temperature range | -25…+85°C |
| Isolation L / L | 1.45 kVdc / 60 s (2) |
| Isolation L / PE | 2.25 kVdc / 60 s (2) |
| Protection degree | IP 00 |
| Connection terminal | flat plug (10 A) and screw (20 A) |
| Housing material | metallic |
| Dimensions (LxHxD) | 50x85x44mm |
| Approximate weight | |
| Mounting information | screw fixing, on metal panel |
| Common mode (L/PE) attenuation (dB) | |
| 0.15 MHz | 10 |
| 0.5 MHz | 20 |
| 1 MHz | 20 |
| 5 MHz | 20 |
| 10 MHz | 30 |
| 30 MHz | 25 |
| Differential mode (L/PE) attenuation (dB) | |
| 0.15 MHz | 10 |
| 0.5 MHz | 20 |
| 1 MHz | 25 |
| 5 MHz | 25 |
| 10 MHz | 30 |
| 30 MHz | 30 |
| ACCESSORIES | |
| APPROVALS AND MARKINGS |    |
For further information see PDF catalog
